3d fiber laser marking machine 500*500mm laser marking
| Product description | |||
| The intelligent 3D curved fiber laser marking machine can realize precise high-speed automatic laser zoom control, and realize three-dimensional 3D laser marking of metal and non-metal materials without being restricted by curved surfaces, shoe uppers, slopes, terraces, and other heights. Fine laser engraving marks on the surface of the object, the maximum marking range is: 300*300*120mm. | |||
| Advantage function | |||
| 1.Adopting leading three-axis dynamic focusing technology to realize large-format laser marking of flat and 3D curved surfaces; | |||
| 2.The equipment can be equipped with assembly line components to realize the on-line flying marking function of the product and improve the efficiency of laser processing; | |||
| 3.Modular design, easy to disassemble, transport and transfer, some functions can be freely selected, making product upgrade and maintenance easier; | |||
| 4.The self-developed marking software system supports multi-language switching, multiple graphics format file import, graphics drawing and editing, powerful functions, friendly interface, simple and fast operation, easy to learn and easy to use; | |||
| 5.Support intelligent production bus docking, including customer's MES system, product traceability system, etc. | |||
| Basic parameters | |||
| Model | YB-3D | ||
| Laser power (w) | 20-50 | ||
| Working area (X*Y*Z) (mm) | 200*200*60/300*300*120 | ||
| Average spot diameter (um) | 32.8/45.1 | ||
| Marking speed (mm/s) | 7000 | ||
| Minimum character (mm) | 0.3 | ||
| Equipment power (kw) | <0.5 | ||
| Power supply | AC220V, 50HZ | ||
| Working environment | Temperature: 5-35℃ Humidity: ≤80% (no condensation) | ||
| Application show | |||
| (1) Quality: 100% brand new with CE certificate, product in 2022. | |
| (2) Delivery time: 3-15 working days after confirmation of the deposit. | |
| (3) Payment term: 100% by T/T as down-payment. | |
| (4) Packing: Export packing standard, suitable for equipment seaworthy transportation. | |
| (5) Starting up and commissioning | |
| Seller takes charge of commissioning machine before shipment. If buyer needs seller's engineer to test this machine in their plant, they should pay food, hotel and local transport. | |
| (6) Guarantee | |
| (6.1) Guarantee period services: 12 months | |
| During this guarantee period, Company will provide replacement without any charge in case of quality discrepancy caused by us. If the malfunctions are caused by your incorrect operations, Company will provide the buyer components at cost price. | |
| (6.2) Long-term service: | |
| Company will charge the buyer cost price of components beyond one year and provide long-term technical guide. | |
| (7) Offer validity date: 30 days |
Packaging Details
1. Standard export wooden cases with sponge filled inside for packing protection.
2. The Wooden case is fumigation free. Suitable both by sea and by air.
3. Express door to door
